產品概覽
DX51D由卿山鋼鐵按出口採購場景供貨，適用於屋面壓型、風管與出口圍護。技術確認重點包括DX51D牌號、鋅層、厚度、寬度與海運包裝，並可配合 EN 10204 3.1 質保書與第三方檢驗。請提供牌號、尺寸、數量、用途與目的港以獲取可執行報價。
按訂單確認數據
DX51D DX51D+Z SGCC EN 10346 ASTM A653 commercial GI practice when agreed
DX51D Galvanized Steel Coil
DX51D由卿山鋼鐵供應，適用於屋面壓型、風管與出口圍護。下單前請確認DX51D牌號、鋅層、厚度、寬度與海運包裝、數量與目的港。
- 最小起訂
- 通常 1 個整櫃起訂
- 交貨週期
- 確認後 7-21 個工作日
- 產地
- 中國
- 月供應能力
- 月度供應能力 5,000+ 噸
- 標準
- EN 10346, ASTM A653 commercial GI practice when agreed, ASTM A653, JIS G3302 +1
- 證書
- EN 10204 3.1 / MTC
- 包裝
- 採用適合海運出口的包裝，並提供打包與裝櫃照片。
產品技術規格銘牌 按訂單確認數據
技術參數
- Grade
- DX51D / DX51D+Z
- Standards
- EN 10346 (ASTM A653 class when agreed)
- Thickness × width
- Confirm mill range and forming line limits
- Grade
- DX51D+Z / SGCC class (or agreed commercial GI equivalent)
- Standards
- EN 10346, ASTM A653, JIS G3302 as contracted
- Thickness
- Common export band about 0.3–2.5 mm (confirm RFQ range)
物流發運
- 最小起訂
- 通常 1 個整櫃起訂
- 交貨週期
- 確認後 7-21 個工作日
- 產地
- 中國
- 月供應能力
- 月度供應能力 5,000+ 噸
完整規格
| 參數 | 取值 |
|---|---|
| Product form | Hot-dip galvanized steel coil |
| Grade | DX51D / DX51D+Z |
| Standards | EN 10346 (ASTM A653 class when agreed) |
| Coating | Zinc mass class per PO (e.g. Z100–Z275) |
| Thickness × width | Confirm mill range and forming line limits |
| Documents | MTC EN 10204 3.1 with coil/heat identity |
| Export packing | Seaworthy coil packing, eye-to-sky/wall as ordered |
| Product | Hot-dip galvanized steel coil (GI) |
| Grade | DX51D+Z / SGCC class (or agreed commercial GI equivalent) |
| Standards | EN 10346, ASTM A653, JIS G3302 as contracted |
| Zinc coating | Z80–Z275 class options; other coating masses by order confirmation |
| Thickness | Common export band about 0.3–2.5 mm (confirm RFQ range) |
| Width | About 600–1500 mm full-width or slit width by process |
| Surface | Regular / minimized / zero spangle; passivation, oil, or dry |
| Coil ID / weight | 508 / 610 mm ID class; coil weight per unloading limits |
| Documents | EN 10204 3.1 MTC by heat/batch; inspection when ordered |
| Packing | Seaworthy coil packing with edge and moisture protection |
典型應用
- Roofing and wall profile roll-forming
- Duct and HVAC systems
- Commercial cladding and gutters
- General galvanized forming export
採購工具（替代重複 SKU）
皺紋/啞光、波紋/梯形、分條寬度寫進 RFQ 與工具頁，不另開近重複產品頁。
詢價文檔與交付
包裝、MTC 與驗貨路徑 — 寫入詢盤可加快可執行報價。
包裝與交付
按訂單確認包裝採用適合海運出口的包裝，並提供打包與裝櫃照片。
質量保障
文件按訂單提供每批貨可按訂單配套 MTC、檢驗協助與出口資料。
交付可信度
倉儲、驗貨與產品用途
固定交付證明 + 本產品 applications 對齊的用途說明 — 詢價前確認庫存、驗貨與終端場景。
常見問題
常見問題
What do I need for a firm DX51D GI coil quotation?
Send grade (DX51D+Z or agreed equivalent), zinc coating mass, thickness, width, surface, quantity or container target, coil weight/ID preference, destination port, packing, and whether EN 10204 3.1 MTC or third-party inspection is required.
How is DX51D different from structural galvanized grades?
DX51D is a commercial forming grade for roofing and light fabrication. Structural coated grades (for example S280GD / S350GD class) need higher strength confirmation—state the mechanical requirement on the RFQ.
Can you supply sheet instead of coil?
Yes. Confirm cut length and flatness for sheet, or open the DC01 galvanized sheet page when fixed blanks are preferred over continuous coil feed.
What packing is used for export GI coil?
Seaworthy coil packing with waterproof wrap, edge protection, and steel strapping is selected by order. Eye-to-sky or eye-to-wall orientation can be discussed with the shipping plan.
